HC SEANAV – Integrated Navigation system |
|
Compact solution for both civilian and military small to medium
vessels |
| |
| |
HC SEANAV is a fully integrated platform for Navigation in real time as well as Analyze of collected
information
-
All functions are seamless integrated in one application
with the possibility to split functions over several
workstations sharing the same information
-
Our Chart engine and Graphic viewer are developed for high
speed performance, clarity and reliability
-
Standardized and modular architecture permits cost effective
scalability, integration with external systems and
customizing
-
Vector charts according to IHO S-57 Transfer Standard and
IHO S-63 Data Protection Scheme secure the supply of charts
covering the whole word
|
 |
|
|
| |
| |
|
HC SEANAV – Advanced Navigation system |
|
Safe and reliable navigation in the archipelago and at open sea |
| |
| |
|
 |
HC SEANAV is developed for navigation and safety requirements
according to the IHO ECDIS standard
-
Combination of graphical and alphanumerical presentation
together with audio alarms for critical events and
exceptions makes the navigation safe
-
Multiple sources for own position and ship data as well as
multi channel track of AIS and Radar tracks secure safe
positioning relative surrounding vessels
-
Advanced route tracking with automatic calculation of Wheel
Over Position, CPA and arrival zones together with the
optional use of the autopilot control
-
Graphical route planning with automatic warning for hazards
in user defined safety zones enable safe, fast and easy
planning of the route
|
|
|
| |
| |
|
HC MARINE – Complete solution for small and medium vessels |
|
Scalable and extendable platform for maritime navigation and
management |
| |
| |
|
 |
HC MARINE has a flexible architecture suitable for very small up
to large environments with several simultaneous users
-
From a single laptop up to network based client server
solutions which enable users to share information and
database but work with different tasks
-
Client application is fully configurable at runtime allowing
the users to switch tasks without closing down the client
-
Server and client application are identical which makes it
possible to scale up and extend the system without any need
to change existing environment
-
Modular and standardized architecture enables a cost
effective solution for all needs to interface and connect
external systems
|
| |
| |
|
HC SEANAV – One application configured and equipped for
different needs |
|
Standardized architecture enables low cost and fast development
as well as reliable maintenance and support |
| |
| |
HC SEANAV Workstation
1)
-
Microsoft Windows 10 Pro
-
Microsoft SQL Server 2012 Express
-
Intel (R) Core(TM) i5-6400 CPU
-
Intel (R) HD Graphics 630 GPU
-
Display resolution, 1920 x 1080
-
Display colors, 32 bit
-
RAM, 16 GB
-
HDD, 500 GB
-
Ethernet, TCP/IPv4
|
HC SEANAV Server
2)
-
Microsoft Windows Server 2019
-
Microsoft SQL Server 2012
-
Intel (R) Xeon (R) Silver 4208 CPU
-
Intel (R) HD Graphics 630 GPU
-
Display resolution, 1920 < 1080
-
Display colors, 32 bit
-
RAM, 32 GB
-
HDD, 1000 GB
-
Ethernet, TCP/IPv4
|
 |
| 1)
Standard, Professional and Enterprise solutions |
2)
Enterprise solution |
|
| |
|
|
 |
Overview |
|
|
|
|
| |
|
|
HC ITECH AB |
+46 739-42 04 09 |
info@hc-itech.com |
|
|
2021.01 |
| |
